| name | Introduction and Explanation | ||
| Overall Size | 2900mm*2600mm*2450mm | ||
| Machine construction | Heavy duty overall welding heat treatment bed | ||
| Working Size | 1000mm*800mm*300mm | ||
| XYZAB |
X:1300mm Y:950mm Z:500mm A: ∞ B： -90°~+90° |
||
| Transmission | rack+Screw rod | ||
| Reducer | Planet reducer | ||
| Spindle | 9KW Air cooling spindle | ||
| Tool Magazine | 8 | ||
| Motor and driver | Servo motor | ||
| Control cabinet | Independent air-cooled CNC cabinet | ||
| Voltage | AC 380V ± 10% 50/60Hz | ||
| Air pressure | 0.8MPa | ||
| Weight | 2500KG | ||
|
|||
